Number of Channels

2

Fixed Output Level

2.0Vrms Unbalanced

4.0Vrms Balanced

Variable Output Level

N/A

Output Impedance

600 ohms Unbalanced and Balanced

Frequency Response

4Hz to 40kHz, +0.5, -2dB (SACD)

4Hz to 20kHz, ±0.5dB (CD)

Signal To Noise Ratio

Better than 108dB (A-weighted)

Dynamic Range

Better than 100dB

Total Harmonic Distortion

0.003% @ 1000Hz (SACD)

0.002% @ 1000Hz (CD)

Channel Separation

Better than 98dB (1,000Hz)

Headphone Output Impedance

N/A

Digital-to-Analog Converter (DAC) Type

2-channel, 32-bit/192kHz PCM/DSD

Coaxial Sample Rate

N/A

Optical Sample Rate

N/A

USB Sample Rate

N/A

Digital Coaxial Input

N/A

Digital Optical Input

N/A

Digital Output Sample Rate

Up to 24-bit/192kHz

Digital Optical Output

-15dbm to -21dbm

Digital USB Input Type

N/A

Digital Coaxial Output

0.5V p-p/75 ohms

Digital XLR Output

N/A

Digital MCT Output

N/A

Digital Output Jitter

N/A

Balanced Fixed Output

1

Unbalanced Fixed Output

1

Balanced Variable Output

0

Unbalanced Variable Output

0

Digital Coaxial Input

0

Digital MCT Input

0

Digital Optical Input

0

Digital USB Input

0

Digital USB Input Type

N/A

Digital Coaxial Output

1

Digital MCT Output

0

Digital Optical Output

1

Digital XLR Output

0

Headphone Output

0

RS232 Control Input

0

Power Control Input

1

Power Control Output

1

Rear Panel Data Input

1

Rear Panel IR Sensor Input

1

Disc Capacity

1

Disc Formats

CD, SACD, MP3 and WMA

Laser Type

Twin Beam

Laser Beam Wavelength

650nm (SACD)

790nm (CD)

Laser Power

CLASS IIa/CLASS I

Standby Power Requirement

<0.5 watt

Unit Dimensions (W x H x D)

17-1/2" (44.45cm) x 6" (15.24cm) x 19" (48.3cm) Note: When the Disc Tray is opened, the panel clearance required in front of mounting panel is 6-3/4 inches (17.2cm).

Unit Weight

28 lbs (12.7 kg)

Shipping Weight

42.5 lbs (19.2 kg)
