Key Features:

• 1/2.7" Progressive Scan CMOS
• BLC/3D DNR/ROI/HLC
• 2560 × 1920 @15fps
• 2.7 to 13.5 mm varifocal lens
• IP67
• H.265+, H.265, H.264+, H.264
• 2 Behavior analyses
• Color: 0.01 Lux @(F1.2; AGC ON), 0.02 Lux @ (F1.6, AGC ON)

-----------------------------

Camera

• Image Sensor 1/3" Progressive Scan CMOS
• Min. Illumination Color: 0.01 Lux @(F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON)
• Shutter Speed 1/3 s to 1/100, 000 s, support slow shutter
• Slow Shutter Yes
• Auto-Iris No
• Day & Night IR cut filter
• Digital Noise Reduction 3D DNR
• WDR 120 dB
• Angle Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotation: 0° to 360°

Lens

• Focal Length 2.7 to 13.5 mm
• Aperture F1.6
• Focus -I: Manual -IZ: Auto
• FOV Horizontal field of view: 98°to 28° Vertical field of view: 51°to 16° Diagonal field of view: 115°to 32
• Lens Mount Φ14

IR

• IR Range Up to 40 m
• Wavelength 850 nm

Compression Standard

• Video Compression Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
• H.264 Type Baseline Profile/Main Profile/High Profile
• H.265 Type Main Profile
• H.265+ Main stream supports
• Video Bit Rate 32 Kbps to 8 Mbps

Smart Feature-set

• Behavior Analysis Line crossing detection, intrusion detection
• Region of Interest 1 fixed region for main stream and sub-stream


• Max. Resolution 2560 × 1440
• Main Stream Max. Frame Rate 50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
• Sub-stream Max. Frame Rate 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
• Third Stream Max. Frame Rate 50Hz: 1fps (1920 x 1080, 1280 x 960, 1280 x 720, 704 x 480, 640 x 480, 352 x 240, 320 x 240) 60Hz: 1fps (1920 x 1080, 1280 x 960, 1280 x 720, 704 x 480, 640 x 480, 352 x 240, 320 x 240)
• Image Enhancement BLC, 3D DNR, HLC
• Image Settings Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
• Day/Night Switch Auto, scheduled

Network

• Network Storage Support Micro SD/SDHC/SDXC card (128G ), local storage and NAS (NFS,SMB/CIFS), ANR
• Alarm Trigger Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login
• Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
• General Function One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
• Firmware Version 5.5.3
• API ONVIF (PROFILE S, PROFILE G), ISAPI
• Simultaneous Live View Up to 6 channels
• User/Host Up to 32 users 3 levels: Administrator, Operator and User
• Client iVMS-4200, iVMS-4500, iVMS-5200
• Web Browser IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+

Interface

• Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port
• Video Output (Without -Z) 1Vp-p composite output (75 Ω/BNC)
• Audio (-S) 1 input, 1 output
• Alarm (-S) 2 alarm input, 2 alarm output
• Reset Button Yes

General

• Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
• Power Supply 12 VDC ± 20%, 5.5 mm coaxial power plug PoE (802.3af, class 3)
• Power Consumption and Current -Z: 12 VDC, 0.9 A, max. 11 W; PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max. 12.9 W Without -Z: 12 VDC, 0.6 A, max. 7 W; PoE: (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max. 9 W
• Protection Level IP67 TVS 2000V lightning protection, surge protection and voltage transient protection
• Material Metal
• Dimensions Φ 105 mm × 244.4 mm (Φ 4.1" × 9.6")
• Weight Camera: approx. 1035 g (2.3 lb.) With package: approx. 1550 g (3.4 lb.)
