BYPASS MODE (ANALOG INPUTS, TONE / EQ / SUBWOOFERS DISABLED)
|
Frequency Response (-3dB, 50Ω source impedance): 1Hz – 2MHz
Harmonic Distortion (measurement bandwidth: 90kHz):
<0.0004% at 1kHz
<0.0005% at 10kHz
<0.0006% at 20kHz
Intermodulation Distortion (measurement bandwidth: 90kHz): <0.001%
Maximum Input Level BAL / SE (at 0dB gain): 9Vrms (+21.3dBu) / 4.5Vrms (+15.3dBu)
Signal-to-Noise Ratio (A wtd) (22kHz BW, ref 9Vrms): 130dB (133dBA)
Crosstalk (one channel undriven) (BAL / SE): -143dB (100Hz), -140dB (1kHz), -124dB (10kHz)
|
|
PHONO SECTION
(0DB GAIN, BYPASS MODE, XLR2 IN, MAIN XLR OUT)
|
RIAA Deviation (20Hz-20kHz): < 0.2dB
Selectable Load for MM Type (47k II): 50pF, 100pF, 150pF, 200pF, 250pF, 300pF, 350pF, 400pF, 450pF
Selectable Load for MC – Low Output: 7.5Ω, 10Ω, 33Ω, 50Ω, 82Ω, 100Ω, 330Ω, 1kΩ
Load for MC – High Output: 47kΩ
|
|
MM, MC – HIGH OUTPUT
|
Gain (1kHz, 20Ω source impedance): 41.5dB
SNR (22kHz BW, ref 5mVrms in): 86dB (93dB A-wtd)
Max Input Level (overload ref 5mVrms): 11dB (20Hz), 23dB (1kHz), 34dB (10kHz)
|
|
MC - LOW OUTPUT
|
Gain (1kHz, 20Ω source impedance, 1kΩ load): 60dB
SNR (20Hz-20kHz): 68dB (74dB A-wtd)
Max Input Level (overload ref 0.5mVrms, 1kΩ load): 12dB (20Hz), 31dB (1kHz), 52dB (10kHz)
Power (nominal input, 0dB gain, 32Ω load): 540mW
Output Impedance: 6.8Ω
|
|
FILE FORMATS AND SAMPLE RATES SUPPORTED
|
USB-F: 44.1k, 48k, 88.2k, 96k (iOS specific)
USB-B: 32k, 44.1k, 48k, 88.2k, 96k, 176.4k, 192k, 352.8k, 384k
DSD64, DSD128, DSD256 (native – requires Thesycon/Classe driver for Windows) DSD64, (DoP)
Ethernet: WAV, AIFF, ALAC, FLAC, WMA, AAC, MP3, OGG_VORBIS (max 192k/24b) DSD64, (DoP)
SPDIF (opt, coax, AES / EBU): PCM 32k, 44.1k, 48k, 88.2k, 96k, 176.4k, 192k / DSD64
|
|
OUTPUTS
|
HDMI *(optional): 1* (HDMI 2.0b w/HDCP 2.2)
BAL / XLR: 5 (configurable: 2pairs+1sub, 1pair+1sub pair,…)
SE / RCA: 5 (configurable: 2pairs+1sub, 1pair+1sub pair,…)
|
