General description

2-way surround speaker

Enclosure type

closed-box system

Transducer complement

2-way

Bass driver

4"(100mm) composite fibre

Treble driver

25mm microfibre dome

AV shield

No

Sensitivity (2.83V @ 1m)

86dB

Recommended amplifier power

20-80W

Peak SPL

99dB

Nominal impedance

8Ω Compatible

Minimum impedance

4.5Ω

Frequency response (+/-3dB)

105Hz ~ 20kHz

Bass extension(-6dB)

90Hz

Crossover frequency

2.8kHz

Cabinet Volume (in litres)

2.2L

Height (on plinth)

(150+8)mm

Width

160mm

Depth (with terminals)

260mm

Carton size

365 x 345 x 245mm

Net weight

2.85kg/pcs
