Description: •1/2.7" 2.0Megapixel CMOS •25/30fps@1080P •High speed, long distance real-time transmission •Day/Night(ICR), AWB, AGC, BLC, 2DNR •3.6mm fixed lens •IP67, DC12V •Max. IR LEDs length 20m, Smart IR; • Two Years Warranty!
Camera Image Sensor 1/2.7" CMOS Effective Pixels 1920(H)×1080(V), 2MP Scanning System Progressive Electronic Shutter Speed PAL: 1/25~1/100000s NTSC: 1/30~1/100000s Minimum Illumination 0.04Lux/F1.85, 30IRE, 0Lux IR on S/N Ratio More than 65dB IR Distance Up to 20m (66feet) IR On/Off Control Auto / Manual Lens Lens Type Fixed lens / Fixed iris Mount Type Board-in Focal Length 3.6mm Max Aperture F1.85 Angle of View H: 93° Focus Control N/A Close Focus Distance 800mm (2000mm) 31.50'' (78.74'') Pan / Tilt / Rotation Pan/Tilt/Rotation Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotation: 0° ~ 360° Video Resolution 1080P (1920×1080) Frame Rate 25/30fps@1080P, 25/30/50/60fps@720P Video Output 1-channel BNC high definition video output / CVBS video output (Can switch) Day/Night Auto (ICR) / Manual OSD Menu Multi-language BLC Mode BLC / HLC / DWDR WDR DWDR Gain Control AGC Noise Reduction 2D White Balance Auto / Manual Smart IR Auto / Manual Certifications Certifications CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) Interface Audio Interface N/A Eelectrical Power Supply 12V DC ±30% Power Consumption Max. 2.7W (12V DC, IR on) Environmental Operating Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH * Start up should be done at above -40°C (-40°F) Storage Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH Ingress Protection & Vandal Resistance IP67 Construction Casing Plastic Dimensions 70mm×70mm×149mm (2.76"×2.76"×5.87") Net Weight 0.14kg (0.31lb) Gross Weight 0.17kg (0.37lb)
