Amplifier

• Channels:7.2,Object-Based Configuration: 5.2.2
• Power Output per Channel:2-Channel Driven:90 W at 8 Ohms / 20 Hz to 20 kHz / 0.08% THD,125 W at 6 Ohms / 1 kHz / 0.7% THDL,1-Channel Driven:185 W at 6 Ohms / 1 kHz / 10% THD

Audio Processing

• DTS Compatibility:DTS Neural:X, DTS Virtual:X, DTS-HD Master Audio, DTS:X
• Dolby Compatibility:Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Surround, Dolby TrueHD
• Auro 3D Support:No
• Upmixing Technology:Dolby Surround, DTS Neural:X
• Supported File Formats:2.8 MHz DSD, 5.6 MHz DSD, AAC, ALAC, FLAC, MP3, WAV, WMA via USB

Video

• HDR Compatibility:HDR10, HDR10+, Dolby Vision, Hybrid Log Gamma
• Pass-Through Support:8K
• Upscaling:None
• GUI:Yes

Connectivity

• Rear A/V Inputs:6 x HDMI 2.1,2 x Optical TOSLINK,1 x Digital Coaxial,4 x Stereo RCA Composite,1 x Stereo RCA (Phono MM) with Ground Screw
• Rear A/V Outputs:2 x HDMI,2 x RCA Subwoofer Pre-Out
• Front I/O:1 x USB-A Input/Output,1 x 1/4" / 6.35 mm Headphone Output,1 x 1/8" / 3.5 mm Setup Mic Input
• Other Rear I/O:2 x Bluetooth/Wi-Fi Coaxial F-Type Input/Output,1 x FM Coaxial F-Type Input,1 x AM Block Input,1 x RJ45 (Ethernet) Input/Output
• Speaker I/O:7 x Binding Post Pairs (Front, Center, Rear, Rear Surround)
• HDCP Support:Version 2.3
• HDMI Compression Modes:4K120AB / 8K60AB
• Audio Return Channel (ARC):ARC, eARC
• HDMI CEC:Yes
• Media Card Slot:None

Wireless Connectivity

Wireless Audio Protocols:AirPlay 2, HEOS, Roon Ready, Spotify Connect

Control

• External Control Support:Android/iOS Control App
• Virtual Assistant:Apple AirPlay, Alexa Built-in, Works with Google Assistant, Josh.ai, Siri

Tuner Section

• Tuner Type:AM, FM

Power

• Power Consumption:Active: 500 W,No Sound (ECO On): 35 W,No Sound,(ECO Off): 75 W,Standby: 0.1 W,CEC Standby: 0.5 W,Network Standby: 2 W

Physical

• Dimensions (W x H x D):17.1 x 6.6 x 13.0" / 43.4 x 16.8 x 33.0 cm (Antenna Removed),17.1 x 9.3 x 13.4" / 43.4 x 23.6 x 34.0 cm (Antenna Up)
• Weight:21 lb / 9.5 kg

Packaging Info

• Package Weight:25.265 lb
• Box Dimensions (LxWxH):20.3 x 17.9 x 9.9"
