Projection System

DLP

Native Resolution

1080p (1920x1080)

Resolution Support

VGA(640 x 480) to WUXGA(1920 x 1200)‎

Brightness (ANSI lumens)

2000 ANSI lumens‎

Contrast Ratio

10000:1‎

Lens

F=2.59~2.87, f=16.88~21.88‎

Native Aspect Ratio

16:9 (5 aspect ratio selectable)‎

Throw Ratio

1.15~1.5 ‎

Projection Size

30" ~ 300"‎

Zoom Ratio

1.3x‎

Projection Offset

Vertical: 115% +-5%‎

Zoom Ratio

1.2x

Lens

F/# =2.42 - 2.62, f = 19.0 - 22.65 mm

Keystone Adjustment

1D, Vertical +/- 40 degrees

Projection Offset

107%±5%

Resolution support

VGA(640 x 480) to WUXGA(1920 x 1200)‎

Image Size

60''~ 300"‎

3D Compatibility

• Frame Sequential: Up to 60Hz 720p
• Frame Packing: Up to 24 Hz 1080p
• Side by Side: Up to 24Hz 1080p
• Top Bottom: Up to 60Hz 1080p‎

Horizontal Frequency‎

15K~102KHz‎

Vertical Scan Rate

23-120Hz‎

HDTV Compatibility

480i, 480p, 576i, 576p, 720p, 1080i, 1080p ‎

Video Compatibility

NTSC, PAL, SECAM, SDTV(480i/576i),

EDTV (480p/576p, HDTV (720p, 1080i/p 60Hz

Interface

• Computer in (D-sub 15pin) x1( integrate with component)
• HDMI x2 (HDMI with MHL2.0 x1, HDMI x 1)
• MHL x 1(HDMI with MHL2.0)
• Monitor out No
• Composite Video in (RCA) x 1
• S-Video in No
• Audio in (Mini Jack) x 1
• Audio in (L/R) x1
• Audio out (Mini Jack) x 1
• Speaker 10Wx1+Maxx
• USB (Type A) x 1
• USB (Type mini B) x 1 ( service only)
• RS232 (DB-9pin) x 1
• IR Receiver x2 (Front and Rear)‎

Picture Modes

Bright / Vivid/ Cinema / Game/ Sport / User‎‎

DMD Type

DC3‎

Noise Level

34/29 dBA (Normal/Economic mode) ‎

Standby Power Consumption

Automatic power off after 20 minutes without a display source.‎

Light Source

210W‎

Light Source Life*

3000/4500/6500 (hours) ‎* Lamp life results will vary depending on environmental conditions and usage

Power Supply

AC 100 to 240 V, 50/60 Hz‎

Power consumption

270 W(Normal), 220 W(Eco), Standby <0.5W

Dimensions (W x H x D)

346.24 x 101.70 x 214.81 mm‎

Weight

2.75kg‎

Whats in the box

• Remote Control w Battery
• User Manual CD
• QSG
• Warranty Card (by region)
• Power Cord (by region)
