Brightness (ANSI lumens)

3000

Native Resolution

4K UHD (3840×2160)

Native Aspect Ratio

16:09

Contrast Ratio (FOFO)

(w/ Lightsource Dimming), 500,000:1

Display Color

30-bit (1.07 billion colors)

Light Source

4LED

Light Source Life

• Normal 20000 hrs
• ECO 30000 hrs
• SmartEco 20000 hrs

Throw Ratio

1.15 ~ 1.50

Zoom Ratio

1.3x

Lens

F/# = 1.8 - 2.25 mm, f = 17.02 - 22.21 mm

Projection Offset (Full-Height)

110%

Keystone Adjustment

2D, (Auto) Vertical ± 30 degrees; Horizontal ± 30 degrees

Input Lag

(Fast Mode),16 ms (4K@60Hz),4 ms (1080p@240Hz),8 ms (1080p@120Hz)

Resolution Support

VGA (640 x 480) to 4K UHD (3840 x 2160)

Horizontal Frequency

15K~135KHz

Vertical Scan Rate

23~240Hz

HDMI in

(x3) ,HDMI-1 (2.0b/HDCP2.2) ,HDMI-2 (2.0b/HDCP2.2) ,HDMI-Internal (2.0b/HDCP2.2)

USB Type A

(x1) ,USB Type A-1 (2.0/Power Supply2.5A/Service)

RS232 in (DB-9pin)

(x1)

DC 12V Trigger (3.5mm Jack)

(x1)

Speaker

(x2) ,5W Chamber

Audio out (3.5mm Mini Jack)

(x1)

HDMI Audio Return

Yes, eARC, Dolby Atmos

Audio out (S/PDIF)

Multi-Channel, RAW

Built-in OS

Yes, Android 10.0

Bluetooth

Yes, Bluetooth 4.2

Wi-Fi Standard

802.11 a/b/g/n/ac (2.4G/5G)

Wireless Projection

Google Cast

Bluetooth

Yes, Bluetooth 4.2

Resolution Support

VGA (640 x 480) to 4K UHD (3840 x 2160)

Operating Temperature

0~40℃

Remote Control w/ Battery

RCI068

Quick Start Guide

(x1) 21L

Dimensions (WxHxD) (mm)

272 x 197 x 259mm (w/o Adjustment Feet)

Net Weight (kg)

6.4 kg
