Model

HTM72 S2

Description

2-way vented-box system

Features

• Decoupled Carbon Dome tweeter
• Continuum™ cone bass / midrange
• Flowport™

Drive units

• 1x ø25mm (1 in) Decoupled Carbon Dome high-frequency
• 2x ø130mm (5 in) Continuum cone bass / midrange

Frequency range

-6dB at 48Hz and 33kHz

Frequency response

70Hz - 28kHz ±3dB

Sensitivity

87dB spl (2.83Vrms, 1m)

Harmonic distortion

• 2nd and 3rd harmonics (90dB, 1m)
• <1% 100Hz - 22kHz
• <0.5% 200Hz - 22kHz

Nominal impedance

8Ω (minimum 4.3Ω)

Recommended amplifier power

30W - 120W into 8Ω on unclipped programme

Dimensions

• Height: 166.5mm (6.6 in)
• Width: 480mm (18.9 in)
• Depth: 260mm (10.2 in) cabinet only, 275mm (10.8 in) including grille and terminals

Net weight

9.11kg (20.1 lb)

Cabinet finishes

• Gloss Black
• Satin White
• Rosenut

Grille finishes

• Black
• Grey (Satin White only)
