Rear A/V Inputs

• 7 x HDMI
• 2 x Optical TOSLINK
• 2 x Digital Coaxial
• 2 x 3RCA Component
• 4 x RCA Composite
• 6 x Stereo RCA
• 1 x Stereo RCA (Phono) with Ground Screw

Rear A/V Outputs

• 2 x HDMI
• 1 x HDMI Zone 2
• 1 x 3RCA Component
• 1 x RCA Composite
• 1 x RCA Composite Zone 2
• 1 x Stereo RCA Zone 2 Pre-Out
• 1 x Stereo RCA Zone 3 Pre-Out
• 1 x 13-Channel RCA Pre-Out

Front I/O

• 1 x 1/4" / 6.35 mm Headphone Output
• 1 x HDMI Input
• 1 x USB Type-A
• 1 x 1/8" / 3.5 mm Setup Mic Input

Speaker Connectors

11 x Binding Post Pairs

Channels

11.2

Power Output per Channel

• 2-Channel Driven:140 W at 8 Ohms / 20 Hz to 20 kHz / 0.05% THD 175 W at 6 Ohms / 1 kHz / 0.7% THD
• 1-Channel Driven: 250 W at 6 Ohms / 1 kHz / 10% THD

Frequency Response

10 Hz to 100 kHz +1/-3 dB (Direct Mode)

Speaker Impedance

4 to 16 Ohms

DTS Compatibility

DTS:X

Dolby Compatibility

Dolby Atmos

Auro 3D Support

Yes

Upmixing Technology

DTS Neural:X, DTS Virtual:X

HDR Compatibility

HDR10, Dolby Vision, Hybrid Log Gamma

Pass-Through Support

4K60p 4:4:4 (3D, BT.2020)

Upscaling

4K UHD

GUI

Yes

Audio Return Channel (ARC)

Yes

HDMI CEC

Yes

Input Impedance

Line: 47 kOhms

Input Sensitivity

200 mV

Signal to Noise Ratio

Pre-Amp: 102 dB (A-Weighted / Direct Mode)

Wi-Fi

Yes

Bluetooth

Yes

Wireless Audio Protocols

AirPlay, AirPlay 2

Dimensions (W x H x D)

17.1 x 6.6 x 14.9" / 43.4 x 16.7 x 37.9 cm

Weight

32 lb / 14.5 kg
