Channels

7.2 (Object-Based Configuration: 5.2.2)

Power Output per Channel

• 2-Channel Driven: 95 W at 8 Ohms / 20 Hz to 20 kHz / 0.08% THD, 125 W at 6 Ohms / 1 kHz / 0.7% THD
• 1-Channel Driven: 150 W at 6 Ohms / 1 kHz / 1% THD

Frequency Response

10 Hz to 100 kHz +1/-3 dB (Direct Mode)

Speaker Impedance

4 to 16 Ohms

DTS Compatibility

DTS:X

Dolby Compatibility

Dolby Atmos

Auro 3D Support

No

Upmixing Technology

DTS Virtual:X

HDR Compatibility

HDR10, Dolby Vision, Hybrid Log Gamma

Pass-Through Support

4K60p 4:4:4 (BT.2020)

Rear A/V Inputs

• 7 x HDMI
• 2 x Optical TOSLINK
• 1 x Digital Coaxial
• 2 x 3RCA Component
• 2 x RCA Composite
• 4 x Stereo RCA
• 1 x Stereo RCA (Phono) with Ground Screw

Rear A/V Outputs

• 2 x HDMI
• 1 x 3RCA Component
• 1 x RCA Composite
• 2 x RCA Subwoofer Pre-Out
• 1 x Stereo RCA Zone 2 Pre-Out

Front I/O

• 1 x 1/4" / 6.35 mm Headphone Output
• 1 x USB Type-A
• 1 x 1/8" / 3.5 mm Setup Mic Input
• 1 x HDMI

Other Rear I/O

• 1 x FM Antenna Terminal
• 1 x AM Antenna Terminal
• 1 x RJ45 (Ethernet)
• 1 x 1/8" / 3.5 mm (IR) Input
• 1 x 1/8" / 3.5 mm (IR) Output
• 1 x DE-9 (RS-232C) Input
• 2 x Bluetooth/Wi-Fi Antenna Terminal

Speaker Connectors

7 x Binding Post Pairs

HDCP Support

Version 2.2

Input Impedance

47 kOhms

Input Sensitivity

200 mV

Signal to Noise Ratio

100 dB (Direct Mode)

Dimensions (W x H x D)

17.1 x 6.6 x 13.4" / 434.3 x 167.6 x 340.4 mm

Weight

20.7 lb / 9.39 kg
