Channels

7.2

Power Output per Channel

• 2-Channel Driven: 95 W at 8 Ohms / 20 Hz to 20 kHz / 0.08% THD, 125 W at 6 Ohms / 1 kHz / 0.07% THD
• 1-Channel Driven: 150 W at 6 Ohms / 1 kHz / 1% THD, 185 W at 6 Ohms / 1 kHz / 10% THD

Frequency Response

10 Hz to 100 kHz +1/-3 dB (Direct Mode)

Speaker Impedance

4 to 16 Ohms

DTS Compatibility

DTS:X

Dolby Compatibility

Dolby Atmos

Auro 3D Support

No

Upmixing Technology

DTS Virtual:X, Dolby Atmos Height Virtualization Technology

Supported File Formats

2.8 MHz DSD, 5.6 MHz DSD, ALAC, FLAC, MP3, WAV, WMA via USB/Network

HDR Compatibility

HDR10, HDR10+, Dolby Vision, Hybrid Log Gamma

Pass-Through Support

8K60p

Upscaling

8K

Rear A/V Inputs

• 6 x HDMI
• 2 x 3RCA Component
• 2 x RCA Composite
• 2 x Optical TOSLINK
• 4 x Stereo RCA
• 1 x Stereo RCA (Phono) with Ground Screw

Rear A/V Outputs

• 2 x HDMI
• 1 x 3RCA Component
• 1 x RCA Composite
• 1 x Stereo RCA Zone 2 Pre-Out
• 2 x RCA Subwoofer Pre-Out

Front I/O

• 1 x 1/4" / 6.35 mm Headphone Output
• 1 x 1/8" / 3.5 mm Setup Mic Input
• 1 x USB Type-A

Other Rear I/O

• 2 x Bluetooth/Wi-Fi Antenna Terminal
• 1 x RJ45 (Ethernet)
• 1 x AM Antenna Terminal Input
• 1 x FM Antenna Terminal Input
• 1 x DE-9 (RS-232C)
• 1 x 1/8" / 3.5 mm (IR) Input
• 1 x 1/8" / 3.5 mm (IR) Output

Speaker Connectors

7 x Binding Post Pairs

HDCP Support

Version 2.3

Audio Return Channel (ARC)

Yes, eARC

HDMI CEC

Yes

Input Impedance

47 Kilohms

Input Sensitivity

200 mV

Signal to Noise Ratio

100 dB (Direct Mode / IHF-A)

Wireless Audio Protocols

AirPlay 2, HEOS

External Control Support

Control4, Domotz Pro, OvrC

Virtual Assistant Support

Amazon Alexa, Apple Siri, Google Assistant, Josh.ai

Tuner Type

AM, FM

Radio Frequencies

• AM: 520 to 1710 kHz
• FM: 87.5 to 107.9 MHz

AC Input Power

120 VAC, 60 Hz

Power Consumption

• Active: 500 W
• Standby: 0.1 W
• CEC Standby: 0.5 W
• No Sound (ECO On): 35 W
• No Sound (ECO Off): 75 W

Dimensions (W x H x D)

• 17.1 x 6.6 x 13.4" / 43.4 x 16.8 x 34.0 cm (Antenna Down)
• 17.1 x 9.3 x 13.4" / 43.4 x 23.6 x 34.0 cm (Antenna Up)
• 17.1 x 6.6 x 13.0" / 43.4 x 16.8 x 33.0 cm (Antenna Removed)

Weight

21 lb / 9.5 kg
