Projection System

3LCD Technology, RGB liquid crystal shutter

LCD Panel

0.61 inch with C2 Fine

Color Light Output

2,700 Lumen- 1,780 Lumen (economy) In accordance with IDMS15.4

White Light Output

2,700 Lumen - 1,780 Lumen (economy) In accordance with ISO 21118:2012

Resolution

Full HD 1080p, 1920 x 1080, 16:9

High Definition

Full HD 3D

Aspect Ratio

16:9

Native Contrast

70,000 : 1

Light source

Lamp

Lamp

UHE, 200 W, 4,500 h durability, 7,500 h durability (economy mode)

Keystone Correction

Auto vertical: ± 30 °, Manual horizontal ± 30 °

Colour Video Processing

10 Bits

2D Vertical Refresh Rate

192 Hz - 240 Hz

3D Vertical Refresh Rate

400 Hz - 480 Hz

Colour Reproduction

Upto 1.07 billion colours

Throw Ratio

1.33 - 2.00:1

Zoom

Manual, Factor: 1 - 1.6

Lens

Optical

Lens Shift

Manual - Vertical ± 60 %

Screen Size

30 inches - 300 inches

Projection Distance Wide/Tele

2.35 m - 3.82 m ( 80 inch screen)

Projection Lens F Number

1.51 - 1.99

Projection Lens Focal Length

18.2 mm - 29.2 mm

Projection Lens Focus

Manual

Interfaces

USB 2.0 Type B (Service Only), HDMI 1.4, Stereo mini jack audio out, Bluetooth

Android TV

Yes

Security

Kensington lock, Security cable hole

3D

Active

2D Colour Modes

Dynamic, Natural, Cinema, Bright Cinema

3D Colour Modes

3D Dynamic, 3D Cinema

3D Supported formats

Side by side, Top and bottom

Other features

3D depth adjustment, AV Mute Slide, Android TV, Automatic keystone correction, Built-in speaker, Frame interpolation, Game mode, Horizontal and vertical keystone correction, Long lamp life, Quick Corner

Video Color Modes

Cinema, Dynamic, Natural, Bright Cinema

Power consumption

297 Watt, 227 Watt (economy), 0.3 Watt (standby), On mode power consumption as defined in JBMS-84 262 Watt

Heat Dissipation

1,009.8 BTU/hour (max)

Supply Voltage

AC 100 V - 240 V, 50 Hz - 60 Hz

Product dimensions

309‎ x 315 x 122 mm (Width x Depth x Height)

Product weight

3.8 kg

Noise Level

Normal: 36 dB (A) - Economy: 28 dB (A)

Supported Temperature

Operation 5° C - 35° C, Storage -10° C - 60° C

Supported Humidity

Operation 20% - 80%, Storage 10% - 90%

Options

Soft carry case

Loudspeaker

10 Watt

What's in the box

Main unit, Power cable, Remote control incl. batteries, User manual (CD), Warranty card

Room Type / Application

Gaming, Home Cinema, Home Photo, Sports, Streaming, TV & Box sets

Positioning

Ceiling Mounted, Desktop

Colour

White
