DESIGN

10" (254 mm) Driver, 120W RMS (250W Dynamic Peak), Class-D amplifier, App controlled via smartphone, Anthem Room Correction (ARC®) Ready.

AMPLIFIER

250 watts Dynamic Peak; 120 watts RMS

AMPLIFIER FEATURES

Auto-On / Off, improved soft-clipping circuitry

FREQUENCY RESPONSE ON-AXIS

±3 dB from 29Hz – 200Hz

ROOM CORRECTION

Anthem Room Correction (ARC®)

LOW FREQUENCY DRIVER

10" (254 mm) carbon-loaded polypropylene cone

SENSITIVITY ROOM / ANECHOIC

100mV mono (max. volume) /

IMPEDANCE

RCA: 8.3k ohms

FINISHES

Satin Black

WEIGHT

33.5 lbs. (15.23 kg)

LOW FREQUENCY EXTENSION

26 Hz (DIN)

LOW PASS FILTER FREQUENCY

Variable 35Hz - 120Hz; Bypass Option

SUB / SAT PHASE ALIGNMENT

Continuously Variable 0° - 180° Under App. Control

INPUTS

Two RCA (Left and Right/LFE) for left/right lineout or Sub-Out from receiver/processor or other line-level source, Two Speaker Level (Left and Right) for input from amplifier or other speaker level source, One Micro USB for ARC™ and firmware updates

COMPATIBLE PRODUCTS

Defiance WT Wireless Kit (sold separately)

DIMENSIONS HXWXD (INCLUDES GRILLE).

• 15 11/16" × 14 1/4" × 15 5/8"
• (39.9cm × 36.2cm × 39.7cm)
