Design

12" (305 mm) Driver, 120W RMS (250W Dynamic Peak), Class-D™ amplifier, App controlled via smartphone, Anthem Room Correction (ARC®) Ready.

Amplifier

250 watts Dynamic Peak;120 watts RMS

Amplifier Features

Auto-On / Off, improved soft-clipping circuitry

Room Correction

Anthem Room Correction (ARC®) Included

Frequency Response

On-Axis

±3 dB from 23Hz – 200Hz

Low Pass Filter Frequency

Variable 35Hz - 120Hz; Bypass Option

Low Frequency Driver

12" (305 mm) carbon-loaded polypropylene cone

Low Frequency Extension

18 Hz (DIN)

Sub / Sat Phase Alignment

Continuously Variable 0° - 180° Under App. Control

Sensitivity

Room / Anechoic

100mV mono (max. volume) /

Impedance

RCA: 8.3k ohms

Finishes

Satin Black

Inputs

• Two RCA (Left and Right/LFE) for left/right lineout or Sub-Out from receiver/processor or other line-level source
• Two Speaker Level (Left and Right) for input from amplifier or other speaker level source
• One Micro USB for ARC™ and firmware updates

Compatible Products

Defiance WT Wireless Kit (sold separately)

Weight

42 lbs. (19.1 kg)

Dimensions

HxWxD

18" × 16.5 × 17.10"

(45.5cm × 42 × 43.4cm)
