Design

4-driver, 2-way bi-directional surround/rear

Crossover

2nd-order electro-acoustic at 2.0 kHz

Frequency Response

On-Axis

±2dB from 120 Hz - 20 kHz

Frequency Response

30° Off-Axis

(bi-directional soundfield)

High Frequency Driver

Two 1” (25mm) X-PAL™ domes, ferro-fluid damped / cooled, Perforated Phase-Aligning Tweeter (PPA™) Lens

Mid/Bass Frequency Driver

Two 4-1/2" (110mm) mineral-filled polypropylene cones, 1 in (25mm) voice-coils, oversize ceramic / ferrite magnets, steel chassis

Low Frequency Extension

71 Hz (DIN)

Sensitivity

Room / Anechoic

89 dB / 86 dB

Impedance

Compatible with 8 ohms

Suitable Amplifier Power Range

15 - 100 watts

Maximum Input Power

100 watts

Finishes

Black

Weight

7.25 lbs. (3.28 kg)

Dimensions

HxWxD

8.5" × 9.25 × 5.125"

(21.7cm × 23.5 × 13cm)
