Display System

4K SXRD panel, projection system

Size of effective display area

0.74” x 3

Number of pixels

26,542,080 (4096 x 2160 x 3) pixels

Focus

Powered

Zoom

Powered (Approx. x2.06)

Lens shift

• Powered
• Vertical: +85% -80% Horizontal: +/-31%

Throw ratio

1.38 : 1 to 2.83 : 1

Light source

High-pressure mercury lamp, 280 W type

Recommended lamp replacement time

6,000 H (Lamp mode: Low)

Screen size

60” to 300” (1,524 mm to 7,620 mm)

Light output

1800 lm (Lamp mode: High) *2

Colour light output

1,800 lm (Lamp mode: High) *2

Dynamic contrast

350,000: 1

Horizontal

19 kHz to 72 kHz

Vertical

48 Hz to 92 Hz

Accepted digital signals

720 x 576/50p, 720 x 480/60p, 1280 x 720/50p, 1280 x 720/60p, 1920 x 1080/50i, 1920 x 1080/60i, 1920 x 1080/24p, 1920 x 1080/50p, 1920 x 1080/60p, 3840 x 2160/24p, 3840 x 2160/25p, 3840 x 2160/30p, 3840 x 2160/50p, 3840 x 2160/60p, 4096 x 2160/24p, 4096 x 2160/25p, 4096 x 2160/30p, 4096 x 2160/50p, 4096 x 2160/60p

OSD language

18-languages (English, Dutch, French, Italian, German, Spanish, Portuguese, Turkish, Russian, Swedish, Norwegian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Thai, Arabic, Polish)

HDMI1/HDMI2 *3

Digital (RGB/Y Pb/Cb Pr/Cr)

Trigger1 / Trigger2

Minijack, DC 12 V Max. 100 mA

Remote

RS-232C, D-sub 9-pin (male)

LAN

RJ45, 10Base-T/100BASE-TX

IR IN

Mini Jack

USB

DC 5 V, Max. 500 mA

Picture processor

X 1 for projector

Acoustic noise

26 dB *4

Operating temperature / Operating humidity

5°C to 35°C (41°F to 95°F) / 35% to 85% (no condensation)

Storage temperature / Storage humidity

-20°C to +60°C (-4°F to +140°F) / 10% to 90% (no condensation)

Power requirements

AC 100 V to 240 V, 4.6 A to 2.0 A, 50/60Hz

Power consumption

460 W

Standby

0.4 W (when "Remote Start" is set to "Off")

Networked Standby

• 1.0W (LAN) (when "Remote Start" is set to “On")
• When a LAN terminal is not connected, it becomes a low power consumption mode (0.5 W)

Standby Mode / Networked Standby Mode Activated

After about 10 Minutes

3D capability

Yes

3D emitter

Built-in RD emitter

Dimensions (W x H x D) (without protrusions)

• 496 x 205 x 464 mm
• 19 1/2 x 8 3/32 x 18 1/4 inches

Mass

Approx. 14 kg / 31 lb

Supplied accessories

• RM-PJ24 Remote Commander (1)
• Size AA (R6) Manganese Batteries (2)
• Lens Cap (1)
• AC Power Cord (1)
• Operating Instructions (CD-ROM) (1)
• Quick Reference Manual (1)

Replacement lamp

LMP-H280

Notes

• 1 - The figures are expected maintenance time and not guaranteed. They will depend on the environment or how the projector is used.
• 2 - The values are estimate.
• 3 - HDMI Input2 is compatible with HDCP 2.2.
• 4 - They will depend on the environment or how the projectors is used. When under normal environment.
