HDR Compatibility

HDR10, Dolby Vision, Hybrid Log Gamma

Pass-Through Support

4K60p 4:4:4 (BT.2020)

Rear A/V Inputs

• 7 x HDMI
• 3 x Optical TOSLINK
• 3 x Digital Coaxial
• 2 x 3RCA Component
• 4 x RCA Composite
• 7 x Stereo RCA
• 1 x Stereo RCA (Phono) with Ground Screw

Rear A/V Outputs

• 3 x HDMI
• 2 x RCA Subwoofer Pre-Out
• 1 x Stereo RCA Zone 2 Pre-Out
• 1 x Stereo RCA Zone 3 Pre-Out
• 1 x 7-Channel RCA Pre-Out

Front I/O

• 1 x 1/4" / 6.35 mm Headphone Output
• 1 x USB Type-A
• 1 x 1/8" / 3.5 mm Setup Mic Input
• 1 x Stereo RCA Input

Other Rear I/O

• 1 x FM Antenna Terminal
• 1 x AM Antenna Terminal
• 2 x Bluetooth/Wi-Fi Antenna Terminal
• 1 x RJ45 (Ethernet)
• 2 x 1/8" / 3.5 mm (12 V Trigger) Output
• 1 x 1/8" / 3.5 mm (Remote) Input
• 1 x 1/8" / 3.5 mm (Remote) Output
• 1 x DE-9 (RS-232C)

Audio Return Channel (ARC)

Yes

Dimensions (W x H x D)

• 17.1 x 7.5 x 18.6" / 43.5 x 19.1 x 47.3 cm (Antenna Removed)
• 17.1 x 10.6 x 18.6" / 43.5 x 27.0 x 47.3 cm (Antenna Up)

Weight

37.5 lb / 17 kg
