Channels

7.2

Power Output per Channel

• 2-Channel Driven: 90 W at 8 Ohms / 20 Hz to 20 kHz / 0.06% THD
• 1-Channel Driven: 125 W at 8 Ohms / 1 kHz / 0.9% THD, 145 W at 6 Ohms / 1 kHz / 10% THD

Dynamic Power per Channel

• 110 W at 8 Ohms
• 130 W at 6 Ohms
• 160 W at 4 Ohms
• 180 W at 2 Ohms

Upscaling

4K UHD

Rear A/V Inputs

• 5 x HDMI 2.1
• 2 x Digital Coaxial
• 2 x Optical TOSLINK
• 3 x Stereo RCA
• 1 x Stereo RCA (Phono) with Ground Screw
• 1 x 3RCA Component
• 1 x RCA Composite

Rear A/V Outputs

• 1 x Stereo RCA Zone 2
• 2 x RCA Subwoofer Pre-Out
• 2 x HDMI 2.1

Front I/O

• 1 x 1/4" / 6.35 mm Headphone Output
• 1 x USB Type-A
• 1 x 1/8" / 3.5 mm Aux Input
• 1 x 1/8" / 3.5 mm Setup Mic Input
• 1 x Stereo RCA

Other Rear I/O

• 1 x AM Antenna Terminal
• 1 x FM Antenna Terminal
• 1 x 1/8" / 3.5 mm (Remote) Input
• 1 x 1/8" / 3.5 mm (Remote) Output
• 1 x 1/8" / 3.5 mm (12 V Trigger) Output
• 1 x RJ45 (Ethernet) Input
• 2 x Bluetooth/Wi-Fi Antenna Terminal

Speaker Connectors

9 x Binding Post Pairs

HDCP Support

Version 2.2

HDMI CEC

Yes

Wi-Fi

Yes

Bluetooth

2.1 + EDR

Bluetooth Profiles

• A2DP
• AVRCP

Supported Audio Codecs

AAC, SBC

Wireless Audio Protocols

AirPlay

Tuner Type

AM, FM

Dimensions (W x H x D)

• 17.1 x 6.4 x 12.9" / 43.5 x 16.2 x 32.7 cm (Antenna Down)
• 17.1 x 8.9 x 12.9" / 43.5 x 22.5 x 32.7 cm (Antenna Up)

Weight

23.1 lb / 10.5 kg
